Flex OBD Bench ECU is the software package for the Flex programmer which allows you to work on engine ECUs in OBD and Bench mode. DESCRIPTION All ECU protocols in one package The Flex OBD Bench ECU software package is the ideal solution for each tuner who want to have all the protocols for engine ECUs of cars, motorcycles and vans in OBD and Bench mode. Modify and recalibrate using the Flex programmer without the need to open the electronic unit. The right starting point for every chiptuning solution.

Complete Bench - Boot MEDC17 software package for programming BOSCH MEDC17 ECUs directly from the engine control unit connector. DESCRIPTION SW FLEX NEC 76F00XX SLAVE This software package includes protocols for work in JTAG AUD on engine control units that mount NEC76F00xx microprocessors. This family of microprocessors can be found in Toyota Denso 275xxx or 175xxx engine control units. This SW package makes it possible to communicate with the supported units through the JTAG port so in this case, it is necessary to open the control unit.

OBD/BENCH ECUS (CARS, BIKES, VANS) SLAVE On activation of this SW package for FLEX, the user may work on all supported protocols for ECUs in cars, motorcycles and vans in OBD and Bench mode. Thanks to the state-of-the-art FLEX HW, programming in Bench mode guarantees a complete reading and writing of the contents of the control unit with no need to open it.

SOFTWARE FLEX INFINEON TC17XX Bench/Boot – SLAVE With the Bench/Boot MEDC17 Software package, you can now program a great deal of BOSCH MEDC17 controllers directly from the ECU connector without opening the unit. You will never damage a BOSCH MEDC17 ECU again: ONE, because you will no longer need to open it; TWO, because you will no longer have to solder or use a bench to connect to it. SW PACKAGE MEDC17 Bench/Boot With Bench/Boot MEDC17 Software package your interventions will always be safe and reliable over time. You will have complete backup reading even of the EEPROM without having to open the unit just in case you need to bring the ECU to original conditions.

Datalogger Plus: the best ally for each professional tuner Configure your Datalogger Check the compatibility on the vehicle list so select the needed vehicle. Connect the OBDII cable (FLX2.10) and go through the steps of the checklist to carry out a perfect test. Choose the most suitable sensors and values for your analysis, configure their display and jump on the car to make your record. Choose the most suitable parameters The right amount of parameters that could be analyzed depends on the selected model of vehicle, ranging between 50 and 2000 switchable sensors. To minimize configuration times of the most suitable sensors, the software automatically groups the most commonly used parameters in default mode. This significantly saves the user's time and guarantees an intuitive and fast search. Each sensor can be displayed in 5 different modes: graph, numerical value, linear gauge, large gauge and small gauge. Data sampling up to 50Hz in Plus mode The Plus version allows you to record with sampling up to 50Hz. It is possible to share and view your data from any device, when connected to the ECUs, witch adapts automatically on the base of the number of sensors selected by the user. This is to offer maximum efficiency in all conditions and with a sampling rate of up to 20ms. Share and view data directly from the online panel Use the online chart to view and analyze the recording once the test is finished. Share measurements with other users at any time. By clicking on the share button the share link will be generated. The online chart is compatible with any kind of desktop and portable device.

SW FLEX NEXUS MPC5XXX MASTER With this FLEX SW package, the user may work on all supported protocols for ECUs and TCUs in bootloader mode.

MOTOROLA MPC5XX SLAVE SW PACKAGE FOR FLEX The FLS0.3S software package allows the SLAVE user to work on BDM protocols. This programming mode is used for communication with ECUs that mount the Motorola MPC5xx family of microprocessors. This type of microprocessor can generally be found on older generation vehicles fitted with EDC16 or MED9 ECUs. MAGICMOTORSPORT recommends that this SW package be used with FLEX and the complete FLEXible Bench kit (or FLEXible Bench upgrade kit for MAGK00030.V2) to obtain more efficient results and safer working conditions with no connection errors.

SW FLEX RENESAS SH7XXXX SLAVE The FLS0.6S software package contains all the protocols for work in OBD, Boot and Bench on ECUs that mount Renesas SH7xxxx microprocessors. This family of microprocessors is generally supported by DENSO and Continental. This MASTER SW package also includes protocols for work on Kubota tractors via OBD and Bench as well. Thanks to the functions of FLEX, it is also possible to perform a complete read and write directly via OBD on this family of microprocessors. MAGICMOTORSPORT recommends that this SW package be used with FLEX and the KUBOTA OBD socket to FLEX connection cable to obtain more efficient results and safer working conditions with no connection errors.

SW FLEX NEXUS MPC5XXX SLAVE With this FLEX SW package, the user may work on all supported protocols for ECUs and TCUs in bootloader mode.

SW FLEX SIEMENS C165/166/167 SLAVE This FLEX SW package allows work in Bootloader mode on all control units that mount C165/166/167 Siemens microprocessors. This family of microprocessors is generally supported by older generation ECUs like ME7 and EDC15.
